by Master Seo Mar 11. 2022

118.  Limit, Request 8/8

<1> Pod 생성 시 자원 할당량을 명시적으로 제한

<2>  Request 최소 사용량(하한선) 보장

<3>  LimitRange 특정 네임스페이스에서 할당되는 자원의 범위 또는 기본값을 지정

<4> ResourceQuota  특정 네임스페이스에서 사용할 수 있는 자원 사용량의 합을 제한



<1> Pod 생성 시 자원 할당량을 명시적으로 제한


1

Limit

최대 사용량(상한선) 제한


2

limit-pod.yaml


cat  << EOF > limit-pod.yaml

apiVersion: v1

kind: Pod

metadata:

  name: limit-pod

spec:

  containers:

  - name: ubuntu

    image: ubuntu

    command: ["tail"]

    args: ["-f", "/dev/null"]

    resources:

      limits:

        memory: "256Mi"

        cpu: "250m"

EOF


Memory: "256Mi" → 파드의 컨테이너에 최대 메모리 사용량은 256Mi 으로 제한

cpu: "250m" → 250m(밀리코어) 는 0.25 CPU 의미로 해당 파드의 컨테이너는 최대 1CPU의 1/4 만큼의 사이클 사용 가능




3

kubectl apply -f limit-pod.yaml

[root@test11 ~]# kubectl apply -f limit-pod.yaml

pod/limit-pod created


kubectl describe pod limit-pod | grep Limits -A 5

[root@test11 ~]# kubectl describe pod limit-pod | grep Limits -A 5

    Limits:

      cpu:     250m

      memory:  256Mi

    Requests:

      cpu:        250m

      memory:     256Mi




4

# Limits 제한 설정 시, 자동으로 Request 설정됨

kubectl describe nodes <파드가 생성된 노드>


[root@test11 ~]# k get nodes

NAME                    STATUS   ROLES    AGE   VERSION

game1-nodepool-w-11gc   Ready    <none>   40h   v1.21.9


kubectl describe nodes game1-nodepool-w-11gc


[root@test11 ~]# kubectl describe nodes game1-nodepool-w-11gc

Name:               game1-nodepool-w-11gc

Roles:              <none>

Labels:             beta.kubernetes.io/arch=amd64

                    beta.kubernetes.io/instance-type=SVR.VSVR.STAND.C002.M008.NET.SSD.B050.G002

                    beta.kubernetes.io/os=linux

                    failure-domain.beta.kubernetes.io/region=1

                    failure-domain.beta.kubernetes.io/zone=2

                    gpu=ndivia

                    kubernetes.io/arch=amd64

                    kubernetes.io/hostname=game1-nodepool-w-11gc

                    kubernetes.io/os=linux

                    ncloud.com/nks-nodepool=game1-nodepool

                    nodeId=10292321

                    regionNo=1

                    zoneNo=2

Annotations:        alpha.kubernetes.io/provided-node-ip: 10.0.2.14

                    csi.volume.kubernetes.io/nodeid: {"blk.csi.ncloud.com":"10292321","nas.csi.ncloud.com":"game1-nodepool-w-11gc"}

                    io.cilium.network.ipv4-cilium-host: 198.18.0.23

                    io.cilium.network.ipv4-health-ip: 198.18.0.13

                    io.cilium.network.ipv4-pod-cidr: 198.18.0.0/24

                    node.alpha.kubernetes.io/ttl: 0

                    volumes.kubernetes.io/controller-managed-attach-detach: true

CreationTimestamp:  Wed, 09 Mar 2022 18:24:53 +0900

Taints:             <none>

Unschedulable:      false

Lease:

  HolderIdentity:  game1-nodepool-w-11gc

  AcquireTime:     <unset>

  RenewTime:       Fri, 11 Mar 2022 10:44:34 +0900

Conditions:

  Type                 Status  LastHeartbeatTime                 LastTransitionTime                Reason                       Message

  ----                 ------  -----------------                 ------------------                ------                       -------

  NetworkUnavailable   False   Wed, 09 Mar 2022 18:25:49 +0900   Wed, 09 Mar 2022 18:25:49 +0900   CiliumIsUp                   Cilium is running on this node

  MemoryPressure       False   Fri, 11 Mar 2022 10:44:30 +0900   Wed, 09 Mar 2022 18:24:53 +0900   KubeletHasSufficientMemory   kubelet has sufficient memory available

  DiskPressure         False   Fri, 11 Mar 2022 10:44:30 +0900   Wed, 09 Mar 2022 18:24:53 +0900   KubeletHasNoDiskPressure     kubelet has no disk pressure

  PIDPressure          False   Fri, 11 Mar 2022 10:44:30 +0900   Wed, 09 Mar 2022 18:24:53 +0900   KubeletHasSufficientPID      kubelet has sufficient PID available

  Ready                True    Fri, 11 Mar 2022 10:44:30 +0900   Wed, 09 Mar 2022 18:25:43 +0900   KubeletReady                 kubelet is posting ready status. AppArmor enabled

Addresses:

  InternalIP:  10.0.2.14

  Hostname:    game1-nodepool-w-11gc

Capacity:

  cpu:                2

  ephemeral-storage:  51340768Ki

  hugepages-1Gi:      0

  hugepages-2Mi:      0

  memory:             8116376Ki

  pods:               110

Allocatable:

  cpu:                1900m

  ephemeral-storage:  47315651711

  hugepages-1Gi:      0

  hugepages-2Mi:      0

  memory:             7751832Ki

  pods:               110

System Info:

  Machine ID:                 b7b033b860da49e1bcaa24ec03adde26

  System UUID:                34f69dba-cbf0-814e-1028-696855f7f155

  Boot ID:                    2fa14a7c-e877-4357-8788-bd5c00f8584c

  Kernel Version:             5.4.0-65-generic

  OS Image:                   Ubuntu 18.04.5 LTS

  Operating System:           linux

  Architecture:               amd64

  Container Runtime Version:  containerd://1.3.7

  Kubelet Version:            v1.21.9

  Kube-Proxy Version:         v1.21.9

PodCIDR:                      198.18.0.0/24

PodCIDRs:                     198.18.0.0/24

ProviderID:                   navercloudplatform://10292321

Non-terminated Pods:          (19 in total)

  Namespace           Name          CPU Requests  CPU Limits  Memory Requests  Memory Limits  Age

  ---------                   ----                                       ------------  ----------  ---------------  -------------  ---

  default                limit-pod        250m (13%)    250m (13%)  256Mi (3%)       256Mi (3%)     2m31s

  kube-system                 cilium-operator-7c756b4ff5-77m6c           0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system                 cilium-qwjbg                               100m (5%)     0 (0%)      100Mi (1%)       0 (0%)         40h

  kube-system                 coredns-9bbc5d444-qh9pz                    100m (5%)     0 (0%)      70Mi (0%)        170Mi (2%)     40h

  kube-system                 csi-nks-controller-84d675d66d-28zvz        0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system                 csi-nks-node-tn9jw                         0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system                 dns-autoscaler-5c578b9dfb-2pww5            20m (1%)      0 (0%)      10Mi (0%)        0 (0%)         40h

  kube-system                 kube-proxy-fjhfz                           0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system                 metrics-server-8589b99d8f-zb5ms            100m (5%)     0 (0%)      200Mi (2%)       0 (0%)         4h25m

  kube-system                 ncloud-kubernetes-q7lsz                    0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system                 nks-nas-csi-controller-68f4bf8779-7tf8m    40m (2%)      500m (26%)  80Mi (1%)        800Mi (10%)    40h

  kube-system                 nks-nas-csi-node-7gzfd                     30m (1%)      600m (31%)  60Mi (0%)        500Mi (6%)     40h

  kube-system                 nodelocaldns-rrkgp                         100m (5%)     0 (0%)      70Mi (0%)        170Mi (2%)     40h

  kube-system                 snapshot-controller-0                      0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system                 startup-script-rfcgm                       0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  ns1                         pod1                                       0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h15m

  ns1                         pod2                                       0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h15m

  ns2                         pod1                                       0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h2m

  ns2                         pod2                                       0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h2m


Allocated resources:

  (Total limits may be over 100 percent, i.e., overcommitted.)

  Resource           Requests     Limits

  --------           --------     ------

  cpu                740m (38%)   1350m (71%)

  memory             846Mi (11%)  1896Mi (25%)

  ephemeral-storage  0 (0%)       0 (0%)

  hugepages-1Gi      0 (0%)       0 (0%)

  hugepages-2Mi      0 (0%)       0 (0%)

Events:              <none>

[root@test11 ~]#




5

kubectl top pod --use-protocol-buffers=true


root@test11 ~]# kubectl top pod --use-protocol-buffers=true

NAME        CPU(cores)   MEMORY(bytes)

limit-pod   1m           0Mi




6

삭제

kubectl delete -f limit-pod.yaml





<2>  Request 최소 사용량(하한선) 보장


1

cat  << EOF > request-limit-pod.yaml

apiVersion: v1

kind: Pod

metadata:

  name: request-limit-pod

spec:

  containers:

  - name: ubuntu

    image: ubuntu

    command: ["tail"]

    args: ["-f", "/dev/null"]

    resources:

      limits:

        memory: "256Mi"

        cpu: "250m"

      requests:

        memory: "128Mi"

        cpu: "125m"

EOF


 Request 최소 사용량(하한선) 보장



2

kubectl apply -f request-limit-pod.yaml


3


kubectl describe pod request-limit-pod | grep Limits -A 5


[root@test11 ~]# kubectl describe pod request-limit-pod | grep Limits -A 5

    Limits:

      cpu:     250m

      memory:  256Mi

    Requests:

      cpu:        125m

      memory:     128Mi


 Request 최소 사용량(하한선) 보장



4

노드 정보 확인


kubectl describe nodes <파드가 생성된 노드>


[root@test11 ~]# kubectl describe nodes game1-nodepool-w-11gc

Name:               game1-nodepool-w-11gc

Roles:              <none>

Labels:             beta.kubernetes.io/arch=amd64

                    beta.kubernetes.io/instance-type=SVR.VSVR.STAND.C002.M008.NET.SSD.B050.G002

                    beta.kubernetes.io/os=linux

                    failure-domain.beta.kubernetes.io/region=1

                    failure-domain.beta.kubernetes.io/zone=2

                    gpu=ndivia

                    kubernetes.io/arch=amd64

                    kubernetes.io/hostname=game1-nodepool-w-11gc

                    kubernetes.io/os=linux

                    ncloud.com/nks-nodepool=game1-nodepool

                    nodeId=10292321

                    regionNo=1

                    zoneNo=2

Annotations:        alpha.kubernetes.io/provided-node-ip: 10.0.2.14

                    csi.volume.kubernetes.io/nodeid: {"blk.csi.ncloud.com":"10292321","nas.csi.ncloud.com":"game1-nodepool-w-11gc"}

                    io.cilium.network.ipv4-cilium-host: 198.18.0.23

                    io.cilium.network.ipv4-health-ip: 198.18.0.13

                    io.cilium.network.ipv4-pod-cidr: 198.18.0.0/24

                    node.alpha.kubernetes.io/ttl: 0

                    volumes.kubernetes.io/controller-managed-attach-detach: true

CreationTimestamp:  Wed, 09 Mar 2022 18:24:53 +0900

Taints:             <none>

Unschedulable:      false

Lease:

  HolderIdentity:  game1-nodepool-w-11gc

  AcquireTime:     <unset>

  RenewTime:       Fri, 11 Mar 2022 10:49:20 +0900

Conditions:

  Type                 Status  LastHeartbeatTime                 LastTransitionTime                Reason                       Message

  ----                 ------  -----------------                 ------------------                ------                       -------

  NetworkUnavailable   False   Wed, 09 Mar 2022 18:25:49 +0900   Wed, 09 Mar 2022 18:25:49 +0900   CiliumIsUp                   Cilium is running on this node

  MemoryPressure       False   Fri, 11 Mar 2022 10:49:21 +0900   Wed, 09 Mar 2022 18:24:53 +0900   KubeletHasSufficientMemory   kubelet has sufficient memory available

  DiskPressure         False   Fri, 11 Mar 2022 10:49:21 +0900   Wed, 09 Mar 2022 18:24:53 +0900   KubeletHasNoDiskPressure     kubelet has no disk pressure

  PIDPressure          False   Fri, 11 Mar 2022 10:49:21 +0900   Wed, 09 Mar 2022 18:24:53 +0900   KubeletHasSufficientPID      kubelet has sufficient PID available

  Ready                True    Fri, 11 Mar 2022 10:49:21 +0900   Wed, 09 Mar 2022 18:25:43 +0900   KubeletReady                 kubelet is posting ready status. AppArmor enabled

Addresses:

  InternalIP:  10.0.2.14

  Hostname:    game1-nodepool-w-11gc

Capacity:

  cpu:                2

  ephemeral-storage:  51340768Ki

  hugepages-1Gi:      0

  hugepages-2Mi:      0

  memory:             8116376Ki

  pods:               110

Allocatable:

  cpu:                1900m

  ephemeral-storage:  47315651711

  hugepages-1Gi:      0

  hugepages-2Mi:      0

  memory:             7751832Ki

  pods:               110

System Info:

  Machine ID:                 b7b033b860da49e1bcaa24ec03adde26

  System UUID:                34f69dba-cbf0-814e-1028-696855f7f155

  Boot ID:                    2fa14a7c-e877-4357-8788-bd5c00f8584c

  Kernel Version:             5.4.0-65-generic

  OS Image:                   Ubuntu 18.04.5 LTS

  Operating System:           linux

  Architecture:               amd64

  Container Runtime Version:  containerd://1.3.7

  Kubelet Version:            v1.21.9

  Kube-Proxy Version:         v1.21.9

PodCIDR:                      198.18.0.0/24

PodCIDRs:                     198.18.0.0/24

ProviderID:                   navercloudplatform://10292321

Non-terminated Pods:          (19 in total)

  Namespace          Name    CPU Requests  CPU Limits  Memory Requests  Memory Limits  Age

  ---------                   ----                                       ------------  ----------  ---------------  -------------  ---

  default        request-limit-pod         125m (6%)     250m (13%)  128Mi (1%)       256Mi (3%)     114s

  kube-system   cilium-operator-7c756b4ff5-77m6c  0 (0%)    0 (0%)      0 (0%)        0 (0%)         40h

  kube-system   cilium-qwjbg          100m (5%)     0 (0%)      100Mi (1%)       0 (0%)         40h

  kube-system    coredns-9bbc5d444-qh9pz   100m (5%)     0 (0%)   70Mi (0%)     170Mi (2%)     40h

  kube-system   csi-nks-controller-84d675d66d-28zvz    0 (0%)    0 (0%)      0 (0%)   0 (0%)         40h

  kube-system      csi-nks-node-tn9jw         0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system   dns-autoscaler-5c578b9dfb-2pww5   20m (1%)    0 (0%)  10Mi (0%)   0 (0%)     40h

  kube-system     kube-proxy-fjhfz                           0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system   metrics-server-8589b99d8f-zb5ms  100m (5%)  0 (0%)   200Mi (2%)  0 (0%)4h30m

  kube-system    ncloud-kubernetes-q7lsz         0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system   nks-nas-csi-controller-68f4bf8779-7tf8m    40m (2%)   500m (26%)  80Mi (1%)      800Mi (10%)    40h

  kube-system  nks-nas-csi-node-7gzfd    30m (1%)      600m (31%)  60Mi (0%)    500Mi (6%)     40h

  kube-system          nodelocaldns-rrkgp   100m (5%)     0 (0%)      70Mi (0%)        170Mi (2%)     40h

  kube-system                 snapshot-controller-0    0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  kube-system                 startup-script-rfcgm        0 (0%)        0 (0%)      0 (0%)           0 (0%)         40h

  ns1                         pod1                                   0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h20m

  ns1                         pod2                                 0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h20m

  ns2                         pod1                                       0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h7m

  ns2                         pod2                                       0 (0%)        0 (0%)      0 (0%)           0 (0%)         4h7m


Allocated resources:

  (Total limits may be over 100 percent, i.e., overcommitted.)

  Resource           Requests    Limits

  --------           --------    ------

  cpu                615m (32%)  1350m (71%)

  memory             718Mi (9%)  1896Mi (25%)

  ephemeral-storage  0 (0%)      0 (0%)

  hugepages-1Gi      0 (0%)      0 (0%)

  hugepages-2Mi      0 (0%)      0 (0%)

Events:              <none>





kubectl top pod --use-protocol-buffers=true



5

삭제

kubectl delete -f request-limit-pod.yaml





<3>  LimitRange 특정 네임스페이스에서 할당되는 자원의 범위 또는 기본값을 지정


1

LimitRange

특정 네임스페이스에서 할당되는 자원의 범위 또는 기본값을 지정

일반 사용자가 리소스 사용량 정의를 생략하더라도 자동으로 Pod 의 리소스 사용량을 설정


2

limitrange.yaml


cat  << EOF > limitrange.yaml

apiVersion: v1

kind: LimitRange

metadata:

  name: limit-range

spec:

  limits:

  - default:               # 1. 자동으로 설정될 기본 Limit 값

      memory: 256Mi

      cpu: 250m

    defaultRequest:        # 2. 자동으로 설정될 기본 Request 값

      memory: 128Mi

      cpu: 125m

    max:                   # 3. 자원 할당량의 최대값

      memory: 0.5Gi

      cpu: 500m

    min:                   # 4. 자원 할당량의 최소값

      memory: 100Mi

      cpu: 100m

    type: Container        # 5. 각 컨테이너에 대해서 적용

EOF




3

kubectl apply -f limitrange.yaml


kubectl get limitranges


[root@test11 ~]# kubectl get limitranges

NAME          CREATED AT

limit-range   2022-03-11T01:55:31Z



kubectl describe limitranges limit-range


[root@test11 ~]# kubectl describe limitranges limit-range

Name:       limit-range

Namespace:  default

Type        Resource  Min    Max    Default Request  Default Limit  Max Limit/Request Ratio

----        --------  ---    ---    ---------------  -------------  -----------------------

Container   cpu       100m   500m   125m             250m           -

Container   memory    100Mi  512Mi  128Mi            256Mi          -

[root@test11 ~]#




4

pod 생성

kubectl run webpod --image nginx


kubectl describe pod webpod | grep Limits -A 5


pod/webpod created

[root@test11 ~]# kubectl describe pod webpod | grep Limits -A 5

    Limits:

      cpu:     250m

      memory:  256Mi

    Requests:

      cpu:        125m

      memory:     128Mi




5

삭제

kubectl delete pod webpod


6

초과 pod 생성 시도?


cat  << EOF > pod-exceed.yaml

apiVersion: v1

kind: Pod

metadata:

  name: pod-exceed

spec:

  containers:

  - name: ubuntu

    image: ubuntu

    command: ["tail"]

    args: ["-f", "/dev/null"]

    resources:

      limits:

        memory: "800Mi"

        cpu: "750m"

      requests:

        memory: "500Mi"

        cpu: "500m"

EOF





kubectl apply -f pod-exceed.yaml


[root@test11 ~]# kubectl apply -f pod-exceed.yaml

Error from server (Forbidden): error when creating "pod-exceed.yaml": pods "pod-exceed" is forbidden: [maximum cpu usage per Container is 500m, but limit is 750m, maximum memory usage per Container is 512Mi, but limit is 800Mi]



7

삭제

kubectl delete -f limitrange.yaml





<4> ResourceQuota  특정 네임스페이스에서 사용할 수 있는 자원 사용량의 합을 제한


1

ResourceQuota

특정 네임스페이스에서 사용할 수 있는 자원 사용량의 합을 제한


2

네임스페이스에서 할당할 수 있는 자원(CPU, 메모리, 퍼시스턴트 볼륨 클레임의 크기 등)의 총합을 제한할 수 있습니다

네임스페이스에서 생성할 수 있는 리소스(서비스, 디플로이먼트 등)의 개수를 제한할 수 있습니다.


3

cat  << EOF > ns3-quota-pod-count.yaml

apiVersion: v1

kind: Namespace

metadata:

  name: ns3

---

apiVersion: v1

kind: ResourceQuota

metadata:

  name: resource-quota-pod-count

  namespace: ns3

spec:

  hard:

    count/pods: 3

    count/services: 1

EOF




4

kubectl apply -f ns3-quota-pod-count.yaml


[root@test11 ~]# kubectl apply -f ns3-quota-pod-count.yaml

namespace/ns3 created

resourcequota/resource-quota-pod-count created



[root@test11 ~]# k get ns

NAME              STATUS   AGE

default           Active   40h

kube-node-lease   Active   40h

kube-public       Active   40h

kube-system       Active   40h

ns1               Active   4h32m

ns2               Active   4h32m

ns3               Active   3s




5


kubectl get namespaces ns3

kubectl get quota

kubectl get quota -n ns3


[root@test11 ~]# kubectl get quota

No resources found in default namespace.


[root@test11 ~]# kubectl get quota -n ns3

NAME                       AGE   REQUEST                                LIMIT

resource-quota-pod-count   54s   count/pods: 0/3, count/services: 0/1

[root@test11 ~]#



6

포드 생성 : 3개까지는 정상 생성되고 이후 4개부터는 포드 개수 제한으로 생성 실패!

for i in {1..4}; do kubectl run -n ns3 over-pod-$i --image=nginx --restart=Never; echo "--------------"; sleep 10; done;


[root@test11 ~]# for i in {1..4}; do kubectl run -n ns3 over-pod-$i --image=nginx --restart=Never; echo "--------------"; sleep 10; done;

pod/over-pod-1 created

--------------

pod/over-pod-2 created

--------------

pod/over-pod-3 created

--------------

Error from server (Forbidden): pods "over-pod-4" is forbidden: exceeded quota: resource-quota-pod-count, requested: count/pods=1, used: count/pods=3, limited: count/pods=3

--------------



7

삭제

kubectl delete -f ns3-quota-pod-count.yaml




https://brunch.co.kr/@topasvga/2240

감사합니다.








매거진의 이전글 117. 네임 스페이스 이해  7/8
브런치는 최신 브라우저에 최적화 되어있습니다. IE chrome safari
