19탄-27. 테라폼-AWS- 프로덕션 수준의 테라폼
다음은 주말 CloudNet 테라폼 스터디 내용 참고하여 정리한 부분입니다.
https://gasidaseo.notion.site/gasidaseo/CloudNet-Blog-c9dfa44a27ff431dafdd2edacc8a1863
<1> RDS 배포
<2> ASG 배포
<3> ALB 배포
<4> 삭제
<1> RDS 배포
1
# [터미널1] RDS 생성 모니터링
while true; do aws rds describe-db-instances --query "*[].[Endpoint.Address,Endpoint.Port,MasterUsername]" --output text ; echo "------------------------------" ; sleep 1; done
2
터미널2
# RDS 배포
cd /root/terraform-up-and-running-code/code/terraform/08-production-grade-infrastructure/small-modules/modules/data-stores/mysql
# 환경변수에 지정
export TF_VAR_db_username='cloudneta'
export TF_VAR_db_password='cloudnetaQ!'
terraform init && terraform plan
terraform apply -auto-approve
var.db_name
The name to use for the database
Enter a value: masterseodb
terraform-up-and-running20xx21299400000001.c7aitcdywcyg.us-east-2.rds.amazonaws.com 3306 cloudneta
------------------------------
terraform-up-and-running20x400000001.c7aitcdywcyg.us-east-2.rds.amazonaws.com 3306 cloudneta
------------------------------
terraform-up-and-running20221x0000001.c7aitcdywcyg.us-east-2.rds.amazonaws.com 3306 cloudneta
<2> ASG 배포
1
# [터미널2]
while true; do aws ec2 describe-instances --query "Reservations[*].Instances[*].{PublicIPAdd:PublicIpAddress,InstanceName:Tags[?Key=='Name']|[0].Value,Status:State.Name}" --filters Name=instance-state-name,Values=running --output text ; echo "------------------------------" ; sleep 1; done
2
터미널 1
# ASG 배포
cd ~/terraform-up-and-running-code/code/terraform/08-production-grade-infrastructure/small-modules/examples/asg
terraform init
terraform plan
terraform apply -auto-approve
3
------------------------------
terraform-up-and-running None running
------------------------------
terraform-up-and-running None running
------------------------------
terraform-up-and-running None running
------------------------------
terraform-up-and-running None running
------------------------------
terraform-up-and-running None running
<3> ALB 배포
1
터미널1
# ALB 배포
cd ..
cd ~/terraform-up-and-running-code/code/terraform/08-production-grade-infrastructure/small-modules/examples/alb
terraform init && terraform plan
terraform apply -auto-approve
Outputs:
alb_dns_name = "terraform-up-and-running-58544743.us-east-2.elb.amazonaws.com"
2
터미널1
# ALB DNS주소로 curl 접속 확인
ALB 생성후
ALBDNS=$(terraform output -raw alb_dns_name)
while true; do curl --connect-timeout 1 http://$ALBDNS ; echo; echo "------------------------------"; date; sleep 1; done
curl -s http://$ALBDNS
<4> 삭제
cd ~/terraform-up-and-running-code/code/terraform/08-production-grade-infrastructure/small-modules/examples/alb
terraform destroy -auto-approve
cd ~/terraform-up-and-running-code/code/terraform/08-production-grade-infrastructure/small-modules/examples/asg
terraform destroy -auto-approve
cd ~/terraform-up-and-running-code/code/terraform/08-production-grade-infrastructure/small-modules/examples/mysql
terraform destroy -auto-approve
